Home ProductsSand And Dust Test ChamberIEC60529:2001 Programmable Sand And Dust Test Chamber High Standard
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard
Contact Now

IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard

Minimum Order Quantity : 1 set Price : $4500 >=1 Set
Delivery Time : 35 work days Payment Terms : L/C, D/A, D/P, T/T, Western Union
Supply Ability : 30 sets per month
Place of Origin: Guangdong Brand Name: Envsin
Certification: ISO CE Model Number: EFS

Detail Information
Temperature Range: RT+20~80℃ Humidity Range: 10%~30%RH
Warranty: 12 Months Power: AC230V±10% 1/N/E 50Hz
Dust Concentration: 10.6±7 G/m³ Standard: IEC60529:2001
Color: Blue/White
High Light:

programmable Sand And Dust Test Chamber

,

IEC60529:2001 Sand And Dust Test Chamber

,

programmable temperature and humidity chamber

Product Description

Sand Dust Resistance Test Chamber
The Sand Dust Test Chamber is suitable for detecting the sealing performance of the product's shell,mainly to simulate the damage caused by the sandstorm weather to locks,automobile and motorcycle parts,seals,power meters and other products.
Our Service

• Be able to provide a complete testing solution.

• Preferential vendor of Apple, Cisco and Huawei in China

• Perfect systematic pre-sale and after-sale technical support
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 0
Features
• Accept customized design requirements.
• Properties and applications meet the military and industry standards.
• Advanced rotary blowing design to prevent dust from back flow.
• Automatic control the amount of dust/sand and wind to meet the test standards.
• Dynamic adjustment temperature control system: rapid and stable control of test chambers' temperature.• Independent control of temperature and humidity ensures a stable testing condition.
• Fashionable design of modular construction.
• Observation window in testing space with a dust wiper for real-time monitoring.
• Intelligent and independent protection design for overload, overheat, power supply abnormity, overvoltage, component malfunction monitoring.


Products Performance
Model
ESC500
ESC800
ESC1000
ESC1500
Sample holder Dimension (mm)
785×785
790×990
980×980
980×1480
Test Space Dimension (mm)
800W×800D×800H
800W×1000D×1000H
1000W×1000D×1000H
1000W×1500D×1000H
Temp. Range (C°)
RT +20~+80 adjustable
Selective Dustproof
IP5X (Dustproof Test, increase or no negative pressure)
IP6X (Seal Test, increase negative pressure)
Standards
IEC60529:2001
Power
AC230V ±10%, 50Hz, 1/N/PE
Model
ESC
Temp. Range (℃)
RT+20 ~ +80 Adjustable
Humid. Range (%RH)
10~30
Blowing methods
Up and Down, Gyratory Cycle
Time control
0~99h59m59s, adjustable
Dust Blowing Test
GJB-150.12-2009
Dust Concentration (g/m³ )
10.6±7
Speed of Dust Blowing (m/s)
1.5~8.9
Dust Composition
97%~99%  SiO2
Sand Blowing Test
GJB-150.12-2009
Sand Concentration (g/m³)
2.2g±0.5; 1.1g±0.3; 0.18
Speed of Sand Blowing (m/s)
18~30
Sand Diameter (um)
150~850
Dust-Falling Test
GJB-150.12-2009
Dust-Falling Concentration (g/m³ )
0.1~10.6±7
Dust Particle Diameter (um)
20~150
External Dimension (mm)
1300W×1300D×1300H
Power
AC230V±10%, 50Hz, 1/N/PE

Options Accessories

• Independent sensors for protection (NE60519-2.1993)
• Entry ports for testing space
• Power outlets for specimens
• Spare parts package
• E-management and cyber-software
• APP for mobility management
• Sand testing medium
• Dust testing medium
Quality Control
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 1
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 2
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 3
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 4
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 5
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 6
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 7
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 8
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 9
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 10
IEC60529:2001 Programmable Sand And Dust Test Chamber High Standard 11

Standard Version

• 1 Stainless steel shelves
• 1 Screen sieve
