• Equipped with test chamber cover gasket automatic lifting device operation function, good sealing,safe and efficient operation.
• Maintainable reagent bottles,with special design and the supplementary water level observation table are very strong,and convenient to operate and wash.
• Air pressure (saturated) barrel with resistance to high temperature and pressure plastic molding, high strength integrated work, good durability and heat preservation
effect.Laboratory basket designed by plane degree,can be adjusted.
• Equipped with functions of monitoring over temperature protection , water monitoring protection and low water level automatic water supplement function.
• Test chamber cover gasket with transparent glass observation window, combined with mist device, is convenient to observe experiment clearly
• Equipped with intelligent programmable interface LCD touch screen control system, control and monitoring the temperature and humidity,convenient and efficient.
• Running time control function, after the completion of the accumulated running time, the equipment can automatically
stop the test.
• The compressed air supply system adopts multiple sections
of adjustment, with functions of air filtration, drainage, regulating voltage stability.
• Spray method on the principle of "unit, the atomization degree is uniform, non-blocking crystallization, satisfies the requirement of continuous testing.
• Equipped with special glass salt spray nozzle + spray tower, with functions of spray quantity size and spray Angle is adjustable.
• Can be equipped with climate test function, with controlling the cycle corrosion test and high precision temperature and humidity test.
Products Performance
Salty spray tester ESE/Combination
ECSE-270
ECSE-408
ECSE-800
ECSE-1200
Type ECSE Test Space Volume (L)
270L
408L
800L
1200L
Inner Dimentsion (W×D×H)mm
900×600×500
1200×800×500
1600×1000×500
2000×1000×600
External Dimension (W×D×H)mm
2450×1553×1430
2830×1560×1830
2830×1560×1830
3630×1560×1930
Salt water tank volume(L)
25L
40L
40L
60L
Salt Fog/Condensate Test
Temp. Range (℃) :RT+5℃～50℃
Humid. Range :Relative humidity/Saturated Humidity
Saturated Air Barrel Temp Range:RT+5℃～65℃
Salt Spray Sedimentation Rate:1～2ml·80cm²·h /Others are adjustable
Climate Testing
Temp. Range :10℃～80℃
Temp. Deviation:±2.0℃
Temp. Fluctuation:±0.5℃
Temp. Uniformity:±1.0℃
Humid. Range(℃):20%RH～98%RH
Humid. Deviation:+2.0%RH/-3.0%RH
Humid. Fluctuation:±3.0%RH
Humid.Uniformity:±2.0%RH
Control Interface
LCD Touch Screen Digital Control , LED Digital Display control(Touch Screen Adjustable)
Power
AC380V±10%,50HZ,3/N/PE, AC230V±10%,50HZ,1/N/PE
Test Standards
Reference GB,ISO,ASTM,BS,DIN,JIS, etc National or International Standards
Customized Function And Model
Satisfy Diverse Customers' Needs, Can Provide Special Function And Customized Model
ESE-X(X stands for volume)
Type ESE Test Space Volume (L)
108,270,408,600,800,1200
Inner Dimentsion (W×D×H)mm
Reference ECSE Series
External Dimension (W×D×H)mm
The Size Is Smaller Than ECSE Series
Salt water tank volume(L)
Reference ECSE Series
Standard Version
• C-BAR • V Shaped Speciman Rack • Measuring Cylinder • Reagent Grade Analysis Pure Sodium Chloride(NaCl)500g*2
Quality Control
Option Version
• Air Compressor Unit • Reagent Grade Analysis Pure Sodium Chloride(NaCl) • Reagent Grade Copper Chloride(CuCl2HO) • Reagent Crade Glacial Acetic Acid(CH3COOH)
