Rapid Temperature Change Chamber 3-Zone Thermal Shock Chamber Extreme Temperature Testing

Minimum Order Quantity :	1	Packaging Details :	Woden Case
Delivery Time :	2Months~3Months	Payment Terms :	T/T, Western Union,

Place of Origin:	China	Brand Name:	Envsin
Certification:	CE	Model Number:	ET

Detail Information
Product Name:	Thermal Shock Test Chamber(Three Zones)	Warranty:	12 Months
Standard:	IEC 60068-2-14, MIL STD 202	Usage:	Widely Used
Power:	AC380V ±10%, 50HZ, 3/N/PE	Test Zones:	Three Zones
Highlight:	CE thermal shock testing machine , 380V thermal shock testing machine , 380V low temperature test chamber

Product Description

Rapid Temperature Change Chamber 3-Zone Thermal Shock Chamber Extreme Temperature Testing

Functions:Thermal shock chambers are designed to test the durability and reliability of products by exposing them to sudden and extreme temperature changes. These chambers simulate real-world environmental conditions, ensuring products can withstand rapid thermal transitions without performance degradation. The equipment typically includes:
Rapid Temperature Change: Alternates between high and low temperatures in seconds.
Testing Automation: Programmable settings for repeated cycles.
Precision Control: High accuracy in temperature regulation to meet specific testing standards.
Applications:Thermal shock chambers are widely used in various industries to test material integrity and product performance, such as:
Electronics and Semiconductors: Ensuring circuit boards, IC chips, and other components are resistant to temperature-induced stress.
Automotive: Testing engine components, sensors, and electronic systems under extreme conditions.
Aerospace: Evaluating materials and parts used in aircraft and spacecraft.
Battery and Energy: Assessing the safety and performance of lithium-ion and other batteries.
Consumer Products: Verifying product durability, especially for items subjected to varying climates.
Thermal shock chambers are essential for industries requiring high-reliability products, helping manufacturers improve quality, reduce risks, and meet international standards.

Features

Ø The chamber is Fashion designed with modular construction	Ø Design with independent sensors to prevent specimens from damages caused by dewing, overheat, breezeless and smog
Ø 7'' colour touch screen with 32bit control system	Ø Intelligent and high-performance servo refrigerating control technology: energy saving and rapid heating/cooling rate.
Ø Optional App mobility management	Ø Optional network video monitoring and data synchronization
Ø Customer-friendly design: observation window with a reality visualization for real-time monitoring	Ø Automatic reminder of equipment maintenance plans and software of recording malfunction.
Ø Long defrosting cycles:over 700h's running before defrosting	Ø Unique operation mode: make testing area's temperature back to room temperature after tests are finished
Ø 4 load power outlets for specimens with programmable control for protection.	Ø Specialized design of air circulation system inside ensures testing accuracy
Ø the remote-assist service function and teaching CDs are optonal

Rapid Temperature Change Chamber 3-Zone Thermal Shock Chamber Extreme Temperature Testing 1

Specifications

Model	ET450S2	ET4100S2	ET4200S2
	ET550S2	ET5100S2	ET5200S2
	ET650S2	ET6100S2	ET6200S2
Test Space Volume (L)	50	100	200
Test Zones	2
Hot chamber Temp. Range (℃ )	$+50/+200
Cold chamber Temp. Range (℃)	$-80/70	$-80/70	$-75/70
Temp. Constancy (℃ )	±0.3~±1.0
Temp. Homogeneity (℃)	±0.5~±2.0	±0.5~±2.0	±1.0~±2.0
Recovery Time (min)	<1(on Air Outlet)	<5(on Air Outlet)	<5(on Air Outlet)
Test Space Dimension (mm)	400W400D310H	500W500D400H	600W550D600H
External Dimension (mm)	900W2300D2160H	1000W2400D2250H	1200W2500D2200H
Temperature Range(℃)	$-40/150	$-40/150	$-40/150
	$-55/150	$-55/150	$-55/150
	$-65/150	$-65/150	$-65/150
Cooling Methods	Air-Cooled Water-Cooled (IEC 60068-3-5)
Power	AC380V ±10%, 50HZ, 3/N/PE
Compliant with International Standards:
GB/T2423.22		Test Na BS 2011
MIL STD202F (Method 107G)		DIN40046, Test Na
IEC 60068-2-14		JESD22-A101-A

Options	Standard Version
☆ Independent sensors for specimen protection (NE60519-2.1993)	☆ 2Stainless Steel shelves
☆ Spare parts package
☆ E-management and cyber-software
☆ Video monitor system
☆ APP for mobility management
☆ 1 Entry port Φ100mm
☆ Nitrogen gas auxiliary device

Rapid Temperature Change Chamber 3-Zone Thermal Shock Chamber Extreme Temperature Testing 2
