Battery Testing High-Temperature Aging Test Chamber Automotive Industry

Name: Battery Testing High-Temperature Aging Test Chamber Automotive Industry
Brand: Envsin
SKU: EWG
Rating: 4.7 (111 reviews)

Minimum Order Quantity :	1	Packaging Details :	Woden Case
Delivery Time :	2Months~3Months	Payment Terms :	T/T, Western Union, L/C

Place of Origin:	China	Brand Name:	Envsin
Certification:	CE	Model Number:	EWG

Detail Information
Product Name:	High Tempreature Aging Test Chamber	Warranty:	1 Year
Power:	Electronic	Usage:	Widely Used
Color:	White+Blue	Temperature Range:	RT+10℃ ~100℃/400℃/700℃
Highlight:	380V uv test chamber , 1000L uv test chamber , 1000L uv light chamber

Product Description

Battery Testing High-Temperature Aging Test Chamber Automotive Industry

A High-Temperature Aging Test Chamber is designed to simulate the effects of prolonged exposure to high temperatures on materials, products, or components. The chamber maintains a stable, controlled high-temperature environment for testing the durability, stability, and performance of materials and finished goods over extended periods. This test helps assess how products perform when exposed to conditions they may face during their lifecycle, such as extreme temperatures and long-term use.

Key Features:
Precise Temperature Control: The chamber provides consistent high temperatures, often exceeding 100°C, with advanced temperature regulation for accurate simulation.
Stable and Uniform Environment: Ensures that the temperature is evenly distributed throughout the test area, providing reliable and repeatable results.
Advanced Safety Mechanisms: Includes built-in features such as over-temperature protection, alarms, and fail-safe mechanisms to ensure safe operation.
Energy Efficiency: Designed to minimize energy consumption while maintaining the required temperature conditions.
Programmable Control System: Allows users to set specific test durations, temperature ranges, and other parameters according to their needs.

Specifications

Aging Chambers	EWG2003	EWG3003	EWG2010	EWG3010
Test Space Volume (L)	270		1000
Temp. Range (℃)	R. T+20~200	R. T+20~300	R. T+20~200	R. T+20~300
Temp. Constancy (℃)	±0. 1~±0. 8
Temp. Homogeneity (℃)	±0. 5~±2. 0 (RT+20℃~+200℃) , ±1. 5~±3. 5 (200℃~+300℃)
Temp. Deviation (℃)	±0. 5~±2. 0 (RT+20℃~+200℃) , ±0. 5~±2. 0 (200t~+300℃)
Heat Up Time (min)	50 (RT→+200℃) , 90 (RT→+300℃)
Test Space Dimension (mm)	600Wx500Dx900H		850Wx700Dx1000H
External Dimension (mm)	1000Wx780Dx1710H		1250Wx980Dx1850H
Power	AC380V±10%, 50HZ, 3/N/PE
Aging Rooms	EWG25	EWG45	EWG100	EWG120
Test Space Volume (m3)	25	45	100	120
Temp. Range (℃)	RT+10~85
Temp. Constancy (℃ )	±0. 5~±1. 0
Temp. Homogeneity (℃)	±1. 5~±3. 0
Temp. Deviation (℃)	±1. 5~±3. 0
Heating Rate (℃/min)	2℃/min on average
Power	AC380V±10%, 50HZ, 3/N/PE

Applications:

Material Aging Testing: Used to test the aging properties of rubber, plastic, coatings, and other materials that may degrade over time due to heat exposure.
Electronics Testing: Useful for testing the performance of electronic components and devices, ensuring that they can withstand the heat of real-world operating environments.
Automotive Industry: Helps evaluate the long-term durability of automotive parts, such as seals, gaskets, and interior materials, under high-temperature conditions.
Battery Testing: For assessing the stability and lifespan of batteries, especially in electric vehicles, by simulating prolonged high-temperature exposure.
Consumer Electronics: Used in testing the thermal resilience of products like smartphones, laptops, and other consumer electronics that may be exposed to high temperatures during use.
Aerospace and Defense: Ensures that components meet stringent high-temperature performance standards for use in aircraft, spacecraft, and defense equipment.
