Detail Information
Warranty:	12 Months	Humidity Fluctuation:	±1.0%RH~±3.0%RH
Temperature Fluctuation:	±1.0~±0.5℃	Temperature Uniformity:	±0.5~±2.0℃
Cooling Rate(℃/min):	3.0	Heating Rate(℃/min):	4.0
Power:	380V AC±10% 50/60Hz	Usage:	Universal Testing Machine,Process Testing Machine,Temperature Humidity Test Chamber For Resisting Heat,Textile Testing Instrument
Temperature Range:	-70 Degree ~ +100(150) Degree	Product Name:	Temperature Humidity Test
Humidity Range:	20%~98%R.H.(10%-98%R.H / 5%~98%R.H Is The Specific Condition )	Controller:	Programmable LCD Touch Screen,TEMI800 Digital Controller From South Korea
Power Supply:	Can Be Customized	Material:	SUS 304# Stainless Steel
Compressor:	France "Tecumseh"	Standard:	IEC60068-2-1,JIS H8502
Color:	White And Blue	Accuracy / Volatility:	±1.0℃;±2.0%R.H./ ±0.5℃;±2.0%R.H.
High Light:	150 degree Temperature And Humidity Test Chamber , SUS 304 Temperature And Humidity Test Chamber , 150 degree environmental temperature chamber

Product Description

Features

☆ Homogenous temperature linear changing rates: 5℃/min, 10℃/min	☆ Optional remote-assist service function and teaching CDs.
☆ Fashionable desig of modular construction	☆ Automatic reminder of equipment maintenance plans and software of recording malfunction
☆ Dry air blowing system prevents specimen's surfaces from dewing in rapid temperature change	☆ Intelligent and high-performance servo refrigerating control technology: energy saving and rapid heating/cooling rate
☆ 4 load power outlets for specimens with programmable control for protection	☆ Unique operation mode: make testing area's temperature back ro room temperature after tests are finished
☆ Special air circulation system inside ensures testing accurancy	☆ Optonal APP mobility management
☆ Desig with independent sensors to prevent specimens from damages caused by dewing, overheat, breezeless and smog	☆ Automatic water supply with ultrapure filter devices; water shortage reminder function(ECS series)
☆ Special anti-condensation structures design to avoid misjudgment and improve testing accuracy in climate testing	☆ Strong control abilities of extreme-low humidity range 20℃/10% R.H..(ECS Series)

Specification

Model	EC4018	EC7018	EC4034	EC7034	EC4060	EC7060	EC4100	EC7100	EC4150	EC7150
Test Space Volume(L)	190		335		600		990		1540
Temperature Test Parameters:
Temperature. Range (℃)	-42/+180	-72/+180	-42/+180	-72/+180	-45/+180	-72/+180	-45/+180	-73/+180	-42/+180	-73/+180
Temp. Constancy (℃)	±0.1-±0.5
Temp. Homogeneity (℃)	±0.5-±2.0
Heating Rate (℃/min)	4.0	4.0	3.2	3.0	4.0	4.0	4.0	4.0	3.5	3.5
Cooling Rate (℃/min)	4.0	3.0	4.0	3.0	3.0	2.5	3.0	2.5	2.5	2.3
Temp. Max. Thermal Compensation (W)	2800	1500	2800	1500	1500	2500	4500	3000	4200	3000
Climate Test Parameters:
Dewpoint Temp. Range (℃)	+4(-3)-+94 10-98 ±1.0-±3 ±0.1-±0.3 ±0.5-±2.0
Humid. Range (%RH)
Humid.Constancy (%RH)
Temp. Constancy (℃)
Temp. Homogeneity (℃)
Temp and Humid Max.Thermal Compensation (W)	400	400	400	400	500	500	500	500	500	500
Power	AC380V±10%,50HZ,3/N/PE

Optional Accessories:

Standard Version:

• Independent sensors for specimen protection(NE60519-2.1993)

• 1 Entry port Φ100mm
• Drier filter for compressing air
• Automatic water supply device
• Nitrogen gas auxiliary device
• Spare parts package
• E-management and cyber software
• Video monitor system

• 3 Power outlets for specimens
• Left and right entry ports Φ50mm
• Silicon Stoppers for entry ports
• 2 Stainless steel shelves
• 1 Water tank with 20L
• 1 Water filter
