Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing

Minimum Order Quantity : 1 set Price : $8000 >=1 Set
Delivery Time : 35 work days Payment Terms : L/C, D/A, D/P, T/T, Western Union
Supply Ability : 30 sets per month
Place of Origin: Guangdong Brand Name: Envsin
Certification: ISO CE Model Number: ESR

Detail Information

Test Volume: 1500L、3000L And Other Customized Volume Temperature Range: -20℃/-40℃/-70℃~100℃
Humidity Range: 10%~98%RH Light Wavelength: Full Band Spectrum, Simulating Sunlight From 280nm~3000nm
Irradiation Intensity: 55~1200W/m*m Cooling Time: <=40min(no Load)
Heating Time: <=50min(no Load) Temperature Uniformity: ±0.1℃~ ±2.0℃
Temperature Fluctuation: ±1.0 ~ ±0.5℃
Highlight:

multipurpose Solar Simulation Chamber

,

3000L Solar Simulation Chamber

,

3000L uv test chamber

Product Description



Factory Price Solar Simulation Test Chamber

Full-spectrum solar simulation test chamber can be used to evaluate equipment capacity exposure to the sun radiation
under solar radiation heat or photochemical in hot season.

Our Service

• Be able to provide a complete testing solution (customization)

• Patented and eye-catching industrial design

• Preferential vendor of Apple and Cisco in China

• Perfect systematic pre-sale and after-sale technical support
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 0
Specifications





The Temperature Test
No radiation temperature range: -40℃~+120℃
Radiation temperature range: -20℃~+100℃
Temperature uniformity: ≤1.5℃
Temperature deviation: ±2.0℃
Temperature fluctuation: ±0.5℃
Heating rate: ≥5℃/min
Cooling Rate: ≥2℃/min





Temperature And Climatic Test

Temperature range:+20℃~+85℃
Humidity range: 10%RH~98%RH
Temperature uniformity: ≤1.5℃
Humidity uniformity: 3.0%RH
Temperature deviation: ±2.0℃
Humidity deviation: +2/-3%RH
Temperature fluctuation: ±0.5℃
Humidity fluctuation: ±2.0%RH


Solar Radiation Test
UV Exposure Area: >5600cm²
The light wavelength: all band spectrum, simulated sunlight from 280 nm to 3000 nm
Irradiation intensity :(0 ~ 1200) W/M² can be adjusted, and can be recorded continuously during the test
Performance curve diagram
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 1




Full Spectral Image Of The Luminaire

Standards:

GJB150.7-86 Solar radiation test

GJB150A.7-2009 Solar radiation test

IEC60068-2-5 Test SA: Surface solar radiation simulation

GB2423.24 Test SA: Simulate solar radiation on the ground

DIN75220 Changes of automobile components in a sunlight simulator

MIL-STD 810G Environmental engineering related matters and laboratory testing
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 2




Temperature And Humidity Curve Diagram

Temperature range:+20℃~+85℃

Humidity range:10%RH~98%RH

Temperature uniformity: ≤1.5℃

Humidity uniformity: 3.0%RH

Temperature deviation: ±2.0℃

Humidity deviation: +2/-3%RH

Temperature fluctuation: ±0.5℃

Humidity fluctuation: ±2.0%RH




Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 3
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 4
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 5
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 6
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 7
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 8
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 9
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 10
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 11
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 12
Thermal Cycling Test Chambers for Solar Panels Solar Applications Solar Technologies Durability Testing 13
