1000L UV Aging Chambers for Renewable Energy Solar Panel Testing

1000L UV Aging Chambers for Renewable Energy Solar Panel Testing

1000L UV Aging Chambers for Renewable Energy Solar Panel Testing

Brand Name:	Envsin
Model Number:	ESRZ
MOQ:	1 set
Price:	$8000 >=1 Set
Payment Terms:	L/C, D/A, D/P, T/T, Western Union
Supply Ability:	30 sets per month

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong

Certification:

ISO CE

Test Volume:

1000L And Other Customized

Irradiation Intensity:

55～1200W/m²

Light Wavelength:

Simulating Sunlight From 280nm～3000nm

Supply Ability:

30 sets per month

Highlight:

programmable uv aging test chamber

,

1000L uv aging test chamber

,

1000L solar radiation test chamber

Product Description

Walk in Solar Simulation Test Chamber with Full-spectrum

Full-spectrum solar simulation test chamber can be used to evaluate equipment capacity exposure to the sun radiation
under solar radiation heat or photochemical in hot season.

Our Service

• provide a complete testing solution (customization)

• Preferential vendor of Apple and Cisco in China

• Perfect systematic pre-sale and after-sale technical support

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 0

Specifications

The Temperature Test	No radiation temperature range: -40℃～＋120℃
	Radiation temperature range: -20℃～+100℃
	Temp uniformity: ≤1.5℃
	Temp deviation: ±2.0℃
	Temp fluctuation: ±0.5℃
	Heating rate: ≥5℃/min
	Cooling Rate: ≥2℃/min
Temperature And Climatic Test	Temp range:＋20℃～＋85℃
	Humidity range: 10%RH～98%RH
	Temperature uniformity: ≤1.5℃
	Humidity uniformity: 3.0%RH
	Temp deviation: ±2.0℃
	Humidity deviation: ＋2/－3%RH
	Temp fluctuation: ±0.5℃
	Humidity fluctuation: ±2.0%RH
Solar Radiation Test	UV Exposure Area: ＞5600cm²
	The light wavelength: all band spectrum, simulated sunlight from 280 nm to 3000 nm
	Irradiation intensity :(0 ~ 1200) W/M² can be adjusted, and recorded continuously during the test

Performance curve diagram

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 1

Full Spectral Image Of The Luminaire


Standards:

• IEC60068-2-5 Test SA: Surface solar radiation simulation

• DIN75220 Changes of automobile components in a sunlight simulator

• MIL-STD 810G Environmental engineering related matters and laboratory testing

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 2

Temperature And Humidity Curve Diagram

• Temperature range:＋20℃～＋85℃

• Humidity range:10%RH～98%RH

• Temperature uniformity: ≤1.5℃

• Humidity uniformity: 3.0%RH

• Temperature deviation: ±2.0℃

Humidity deviation: ＋2/－3%RH

Temperature fluctuation: ±0.5℃

Humidity fluctuation: ±2.0%RH

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 3

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 4

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 5

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 6

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 7

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 8

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 9

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 10

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 11

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 12

Sunlight Simulation Test Chamber with Full-band Spectrum and High Precision 13
