1540L Compliance with JIS C 60068 and ASTM D4332 Precision Temperature Humidity Test Chamber for Automotive Industry

Minimum Order Quantity : 1 Payment Terms : T/T, Western Union,
Place of Origin: China Brand Name: Envsin
Certification: CE Model Number: EC

Detail Information

Name: Temperature And Climate Test Chamber Customized: OEM,ODM
Test Space Volume: 190L,1540L Humid. Range: 10%RH~98%RH
Heating Rate: 3.0℃/min Cooling Rate: 3.0℃/min
Highlight:

Envsin Temperature And Humidity Test Chamber

,

1540L Temperature And Humidity Test Chamber

,

1540L high low temperature test chamber

Product Description

Constant high-low Temperature And Humidity Test Chamber for materials

This test Chamber significantly provide temperature and humidity variation environment for astronautics, aviation, petroleum, chemical, engineering, military science, automobile, ship, electronics, communication and other scientific research and production unit. it also simulates compatibility test of samples on the condition of temperature and humidity variation environment and provides reliability test and product screening in terms of the safety test of electron compoent.

Features

Fashionable design of modular construction Automatic water supply with ultrapure filter devices(optional)
7'' colour touch screen display and 32bit control system Strong control abilities of extreme-low humidity range 20/10%R.H..
Optional App mobility management Environment-friendly refrigerating control technology:energy saving and rapid heating/cooling rate.
Optional network video monitoring and data synchronization Automatic reminder of equipment maintenance plans and software of recording malfunction.
Special anti-condensation structures to avoid misjudgment Optional remote-assist service function and teaching CDs

1540L Compliance with JIS C 60068 and ASTM D4332 Precision Temperature Humidity Test Chamber for Automotive Industry 0

Specifications

Model EC4018 EC7018 EC4034 EC7034 EC4060 EC7060 EC4150 EC7150
Test Space Volume(L) 190 335 600 1540
Temperature Test Parameters:
Temp. Range (℃) $-42/180 $-72/180 $-42/180 $-72/180 $-45/180 $-72/180 $-42/180 $--73/180
Temp.Constancy(℃) ±0.1 - ±0.5
Temp.Homogeneity(℃) ±0.5 - ±2.0
Heating Rate (℃/min) 4 4 3.2 3 4 4 3.5 3.5
Cooling Rate (℃/min) 4 3 4 3 3 2.5 2.5 2.3
Temp. Max. Thermal Compensation(W) 2800 1500 2800 1500 2500 2500 4200 3000
Climate Test Parameters:
Dewpoint Temp. Range (℃) +4(-3)~+94
Humid. Range (%RH) 10~98
Humid. Constancy(%RH) ±1.0 - ±3.0
Temp. Constancy(℃) ±0.1 - ±0.3
Temp. Homogeneity(℃) ±0.5 - ±2.0
Temp and Humid Max. Thermal Compensation(W) 400 400 400 400 500 500 500 500
Power AC380V±10%,50HZ,3/N/PE
Cooling Methods Air-Cooled



Options Standard Version
Independent sensors for specimen protection 3 Power outlets for specimens
1 Entry port φ 100mm Left and right entry ports φ 50mm
Drier filter for compressing air Silicon stoppers for entry ports
Automatic water supply device 2 Stainless steel shelves
Nitrogen gas auxiliary device 1 Water tank with 20L
Water-Cooled unit 1 Water filter
Spare parts package
E-management and Cybersoftware
APP for mobility management



Application
It is applied to pharmaceuticals, food, cosmetics, textiles, auto parts, packaging materials, building materials, electricity and the electrical products etc; The test Data result which is very useful for scientific research, product development and quality control sector to help them produce high quality anlysis report
1540L Compliance with JIS C 60068 and ASTM D4332 Precision Temperature Humidity Test Chamber for Automotive Industry 1
1540L Compliance with JIS C 60068 and ASTM D4332 Precision Temperature Humidity Test Chamber for Automotive Industry 2
