28m3 Programmable Control Climatic Test Chamber For Temperature Test

28m3 Programmable Control Climatic Test Chamber For Temperature Test
28m3 Programmable Control Climatic Test Chamber For Temperature Test 28m3 Programmable Control Climatic Test Chamber For Temperature Test 28m3 Programmable Control Climatic Test Chamber For Temperature Test

28m3 Programmable Control Climatic Test Chamber For Temperature Test

Product Details:
Place of Origin: China
Brand Name: Envsin
Certification: CE and ISO
Model Number: ETCZ18/4010
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: To Be Negotiated
Packaging Details: Wooden packing
Delivery Time: 30-35 business days after received the payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 25 per month
Contact Now

Detail Information
Product Name: Climatic Test Chamber Keyword: Walk In Test Chamber
Test Dimension: 2250W*2500D*5000H(mm) External Dimension: 2490W*2740D*6860H(mm)
Floor Load: 30000(N/m³) Humid. Range: 15~95(%RH)
Level 1: 2.7(K/min) Level 2: 3.2(K/min)
Temp. Constancy: ±0.1~±0.5 (IEC60068-3-5)(K) Temp.Homogeneity: ±0.5~±3.0 (IEC60068-3-5)(K)
High Light:

28m3 Climatic Test Chamber

,

Envsin Climatic Test Chamber

,

28m3 temperature cycling chamber

Product Description

Programmable Control Climatic Test Chamber For Temperature Test



The climatic test chamber is suitable for large size or a large number of machine products, parts, materials for high temperature, low

temperature, high low temperature cycle test, and humid heat test. It is mainly used to simulate the product under the combined conditions of climate temperature and humidity or under the changing conditions of ambient temperature and humidity to detect whether the adaptation ability and characteristics of the product change.



Products Features:
• Globally advanced modular design.
• Combined seamless welding technology for permanent aniti-deformation building.
• Optional ultrasonic humidification system for high thermal load testing.(Patented)
• 7' colour touch screen display and 32 bit control system; interface Ethernet/USB.
• Optional APP mobility management.
• 4 load power outlets for specimens with programmable control for protection.
• Special air circulation system inside ensures testing accuracy .(Patented)
• Optional network video monitoring and data synchronization.
• Special anti condensation function to protect specimens during climate testing.
• Unique design: no-need defrosting during long period operation in low temperature.
• Optional remote-assist service function and teaching CDs



Specifications:
Temperature Chambers ETZ8/4010 ETZ28/4010
Climate Chambers ECZ8/010 ECZ28/010
Temperature Climate Cycling Chambers

ETCZ8/4010

ETCZ28/4010
Test Space Volume (m³) 8 28
Test Space Dimension (mm) 2000W*2000D*2056H 2250W*2500D*5000H
External Dimension (mm) 2240W*2240D*3800H 2490W*2740D*6860H



Floor Load (N/m³)

30000

ETZ Series: -60,-40 / +80,+100,+150, +180 optional

Temp. Range (℃) (NoLoad)

ECZ Series: 0 / +80,+100 optional
Humid. Range (%RH) ETCZ Series: -60,-40 / +80,+100,+150 optional





Dewpoint Temp. Range (℃)

15~95 (ETZ,ETCZ Series)

+4~+59 / +4~+95

Heating /Cooling Rate (IEC60068-3-5)
Level 1 (K/min) 4.5 1.7
Level 2 (K/min) 5.5 2.0
Temp. Constancy (K) ±0.1~±0.5 (IEC60068-3-5)
Temp.Homogeneity (K) ±0.5~±3.0 (IEC60068-3-5)
Humid. Constancy Entry (%RH) ±1.0~±5.0 (IEC60068-3-5) (ECZ, ETCZ Series)
Door Dimension Power(mm) 900W×1900H(Single door) , 2000W*2000H (Double door)
Power AC 380V±10%, 50HZ , 3/N/PE
Climatic Test Chamber Options Accessories Climatic Test Chamber Standard Version
Independent sensors for specimen protection (NE60519-2.1993) 1 Entry port Φ100mm
1 Entry port Φ50mm 1 Silicon stopper for entry port
Drier filter for compressingair Automatic water supply
Ultrasonic Humidifier 1 Water tank with 20L
Nitrogen gas auxiliary device 1 Water filter
Water-Cooled unit
Spare parts package
E-management and cyber-software
Video monitor system
APP for mobility management



Structure:

28m3 Programmable Control Climatic Test Chamber For Temperature Test 0

1. Chamber Door 2. Observation Window
3. Control Pad 4. Working Lights
5. Cable Port 6. Extensional control pad
7. Wheels 8. Power distribution board



Test Chamber System:

• Test Chamber Refrigeration System:
Refrigeration working mode(Air-cooled)

Structure Mode Integral. (Test space door direction is forward): with single open test chamber door, the right side is the electric control cabin: refrigeration unit, electric control execution device, the main control interface is located in front of the electric control cabin. The test space includes circulating air duct system and air conditioning system: centrifugal fan, air guide, heater, humidifier, refrigeration heat exchanger, temperature and humidity sensor.



• Temp. and Humidity Control System:
Air Control Mode

28m3 Programmable Control Climatic Test Chamber For Temperature Test 1

• Circulation Air:

Full coverage, no temperature difference type air duct structure system:(Patent No:ZL201220245356.8)
28m3 Programmable Control Climatic Test Chamber For Temperature Test 2

• Design structure of moisture dripping proof:

Drip proof protection structure for sample:(Patent No:ZL201220244190.8)

28m3 Programmable Control Climatic Test Chamber For Temperature Test 3
• Test chamber refrigeration system:
Refrigeration working mode(Air-cooled)
Vapour compression refrigeration: By refrigerating medium circulating gasification and liquefaction’s physical energy conversion process in closed loop refrigerating system. Schematic diagram as picture below:
28m3 Programmable Control Climatic Test Chamber For Temperature Test 4

• Controller:

BYT990S touch screen monitor equipped with an integrated industrial computer system to facilitate operation monitoring and documentation.

28m3 Programmable Control Climatic Test Chamber For Temperature Test 5
Core Components:

28m3 Programmable Control Climatic Test Chamber For Temperature Test 6



28m3 Programmable Control Climatic Test Chamber For Temperature Test 7



28m3 Programmable Control Climatic Test Chamber For Temperature Test 8





  • Humidity & temperature sensor                           Rotronic                                              eyc

​

28m3 Programmable Control Climatic Test Chamber For Temperature Test 9 28m3 Programmable Control Climatic Test Chamber For Temperature Test 10 28m3 Programmable Control Climatic Test Chamber For Temperature Test 11



  • Temperature Protector                                       Taiwan CAHO                             South Korea Autonics

​

28m3 Programmable Control Climatic Test Chamber For Temperature Test 12 28m3 Programmable Control Climatic Test Chamber For Temperature Test 13 28m3 Programmable Control Climatic Test Chamber For Temperature Test 14



  • Contactor Relay                                                France Schneider                               South Korea LS



28m3 Programmable Control Climatic Test Chamber For Temperature Test 15 28m3 Programmable Control Climatic Test Chamber For Temperature Test 16 28m3 Programmable Control Climatic Test Chamber For Temperature Test 17



  • SSR Gas Temperature Sensor                             Switzerland CARLO                   South Korea Rainbow



28m3 Programmable Control Climatic Test Chamber For Temperature Test 18 28m3 Programmable Control Climatic Test Chamber For Temperature Test 19 28m3 Programmable Control Climatic Test Chamber For Temperature Test 20



  • Intermediate Relay Pressure Controller                       Japan OMRON                          DenmarkDanfoss​​​
