Laboratory Envsin GB2423.24 UV Lamp Chamber Sunlight Simulation

Minimum Order Quantity : 1 Price : Negotiation
Packaging Details : Well packed in strong wooden case suitable for all types of long distance shipment Delivery Time : 30-35 days after receipt of payment
Payment Terms : L/C, T/T, Western Union Supply Ability : 25 per month
Place of Origin: China Brand Name: Envsin
Certification: CE ISO Model Number: EZH23

Detail Information

Product Name: Solar Simulation Chamber Temperature Range: +20℃~+85℃
Humidity Range: 10%RH~98%RH Temperature Uniformity: ≤1.5℃
Humidity Uniformity: 3.0%RH Temperature Deviation: ±2.0℃
Humidity Deviation: +2/-3%RH Temperature Fluctuation: ±0.5℃
Humidity Fluctuation: ±2.0%RH UV Exposure Area: >5600cm²
High Light:

GB2423.24 uv lamp chamber


Envsin uv lamp chamber


Envsin uv accelerated weathering tester

Product Description

Sunlight Radiation Solar Simulation Chamber Environmental Testing Equipment


The solar simulation chamber can be used to evaluate the ability of equipment directly exposed to solar radiation in hot season to withstand the thermal effect or photochemical effect produced by solar radiation.The solar simulation chamber can test the heat dissipation test samples and non-heat dissipation test samples. For the test of heat dissipation test sample, the heat dissipation power can not exceedthe cooling capacity of the refrigeration system of the test chamber, because the control of temperature and humidity is a dynamic balance process, in different temperature and humidity points, the cooling capacity of the refrigeration system is also accompanied by changes.


Load conditions:
  • The volume of the solar simulation chamber shall be at least 10 times the volume of the test sample
  • The light source in the solar simulation chamber is at least 0.76m away from any surface of the test sample.
  • The solar simulation chamber sample surface and solar simulation chamber(room) any of the inner wall surface distance is not less than 0.3m, the test sample should be placed to ensure that the airflow is not blocked and shielded each other.
The Temperature Test: Temperature And Climatic Test:
No radiation temperature range: -40℃~+120℃ Temperature range:+20℃~+85℃

Radiation temperature range: -20℃~+100℃

Humidity range: 10%RH~98%RH

Temperature uniformity: ≤1.5℃

Temperature uniformity: ≤1.5℃

Temperature deviation: ±2.0℃ Humidity uniformity: 3.0%RH
Temperature fluctuation: ±0.5℃ Temperature deviation: ±2.0℃
Heating rate: ≥5℃/min Humidity deviation: +2/-3%RH
Cooling Rate: ≥2℃/min Temperature fluctuation: ±0.5℃
N/A Humidity fluctuation: ±2.0%RH
Solar Radiation Test:

UV Exposure Area

The light wavelength all band spectrum, simulated sunlight from 280 nm to 3000 nm
Irradiation intensity (0 ~ 1200) W/M² can be adjusted, and can be recorded continuously during the test


  • GJB150.7-86 solar radiation test
  • Gjb150a.7-2009 Solar radiation test
  • IEC60068-2-5 test Sa: surface solar radiation simulation
  • GB2423.24 test Sa: Simulate the solar radiation on the ground
  • DIN75220 automotive components in the sun simulation device changes
  • Mil-STD 810G environmental engineering related matters and laboratory testing



Solar radiation test is a test that will directly harm the health of test personnel. In order to ensure that the prescribed test operation can be carried out correctly, but also for the health and safety of human beings, the operation model of solar radiation test equipment should be carried out by skilled test personnel, and pay attention to wearing protective equipment during the test.
