IEC60068-2-14 252L Climatic Test Chamber , Temperature Humidity Chamber Steel
IEC60068-2-14 252L Climatic Test Chamber , Temperature Humidity Chamber Steel
Contact Now

IEC60068-2-14 252L Climatic Test Chamber , Temperature Humidity Chamber Steel

Minimum Order Quantity : 1 Payment Terms : T/T, Western Union
Place of Origin: China Brand Name: Envsin
Certification: CE Model Number: ETS

Detail Information
Product Name: Environmental Stress Screening Test Chambers Application: Widely Use
Standard: IEC60068-2-14 Certification: CE
High Temperature Zone Range: +50℃/+200 ℃ Low Temperature Zone Range:: -75℃/+70℃
High Light:

252L Climatic Test Chamber

,

IEC60068-2-14 Climatic Test Chamber

,

IEC60068-2-14 temperature humidity chamber

Product Description

Cold rolled steel battery cell Climatic Test Chamber With Fasion Design



This test chambe suitable for assessing the ability of the whole machine, components, parts and other parts to withstand sudden changes in temperature. It can understand the influences of the test sample at one or more times in succession under a certain speed change. The main parameters affecting the temperature change test are the high temperature and low temperature values of the temperature variation range, the temperature change rate, the retention time of the sample at high and low temperatures, and the number of cycles of the test.



Features

★ Design with independent sensors to prevent specimens from damages caused by dewing, overheat, breezeless and smog ★ Intelligent and high-performance servo refrigerating control technology: energy saving and rapid heating/cooling rate

★ Optional network video monitoring and data synchronization

 ★ Automatic reminder of equipment maintenance plans and software of recording malfunction
★ Automatic reminder of equipment maintenance plans and software of recording malfunction ★ Unique operation mode: make testing area's temperature back ro room temperature after tests are finished
★ Customer-friendly design: optional observation window with a reality visualization

IEC60068-2-14 252L Climatic Test Chamber , Temperature Humidity Chamber Steel 0

Specifications



Model ETS5250S3 ETS5340S3
ETS6250S3 ETS6340S3
Test Space Volume (L) 252 335
Test Zone 3
Hot Chamber Temp. Range (℃) +50/+200
Room Temperature Chamber (℃) R.T
Cold Chamber Temp. Range (℃) -1.071428571 -1.071428571
Temp. Constancy (℃) ±0.3 - ±1.0 ±0.3 - ±1.0
Temp. Homogeneity (℃) ±1.0 - ±2.0 ±1.0 - ±2.0
Recovery Time (min) <15min <15min
ESS Temp. Range (℃) -0.44 -0.44
ESS Temp. Rate (℃) 3~15/15~3 (on specimen) 3~15/15~30 (on specimen)
Test Space Dimension (mm) 700W*600D*600H 800W*650D*650H
Exterior Dimension (mm) 1700W*2300D*2250H 1800W*2500D*2300H
Temp. Range two box (℃) -55/+150 -55/+150
Temp. Range three box (℃) -65/+150 -65/+150
Max. Specimens Weight (kg) 50 70
Cooling Methods Water-Cooled (Compliant with IEC 60068-3-5)
Power AC380V±10%,50HZ,3/N/PE
Compliant with International Standards:
IEC 60749-25 (JESD22-A104D) JESD22-A105-B
IEC 60068-2-14NB (JIS C0025NB) IPC-9701
IEC 61747-5 (EIAJED-2531A) SAE-J1211



Options Standard Version
☆ APP for mobility management ☆ 2 Stainless steel shelves
☆ Independent sensors for specimen protection (NE60519-2.1993) ☆ Left and right entry ports Φ50mm
☆ 1 Entry port Φ100mm ☆ 2 Silicon stoppers for entry ports
☆ Nitrogen gas auxiliary device
☆ Spare parts package
☆ E-management and cyber-software
☆Video monitor system
☆ Automatic Water supply device



IEC60068-2-14 252L Climatic Test Chamber , Temperature Humidity Chamber Steel 1
