Industrial Robot Intelligent Temperature Humidity Chamber ISO14001

Minimum Order Quantity : 1 Price : $120,000.00 >=1 Sets
Delivery Time : 35 Payment Terms : T/T, Western Union
Place of Origin: China Brand Name: Envsin
Certification: CE Model Number: EDE4

Detail Information

Product Name: Intelligent Tempreature Tracking Test Chamber Dimension: 1560*2000*2750mm
Power: Electronic Power Supply: AC380V 50HZ
Temperature Range: -40℃/-70℃~150℃ Standard: ISO14001
High Light:

Robot Temperature Humidity Chamber

,

ISO14001 Temperature Humidity Chamber

,

ISO14001 environmental test chamber

Product Description

Industrial Intelligent Temperature Tracking Screening Test Chamber Overview



For industrial equipment production line operation batch, full inspection of industrial products, semi-finished products, devices and other products, intelligent central control system with special fixtures to achieve automatic feeding , intelligent ESS operation, to achieve full test product monitoring multiple temperatures test platform and equipment for intelligent intercommunication between the intelligent terminal of the chamber and the production line, quality and warehouse management and control center.





Specifications

Model

EDE/EHE

EDE/EHE

EDE/EHE

EDE/EHE

EDE/EHE

EDE/EHE

4080-5

7080-5

4180-5

7180-5

4360-5

7360-5

4080-10

7080-10

4180-10

7180-10

4360-10

7360-10

4080-15

7080-15

4180-15

7180-15

4360-15

7360-15

Test Space Volume (L)

775

1800

3550

Temp.Chambers Parameters:

Temp. Range ( ℃ )

-40/+150

-70/+150

-40/+150

-70/+150

-40/+150

-70/+150

Temp.Rapid Change Rang (℃)

-20/+150

-40/+150

-20/+150

-40/+150

-20/+150

-40/+150

Temp.Rapid Change Rate (℃/min)

5, 10, 15, 20 (No Load)

Temp. Accuracy (℃)

Constancy : ±0.1 ±0.8 ; Homogeneity: ±0.5 ±2.0 ((No Load)

EHE Series Climate Chambers Parameters:

Temp. Range (℃)

10 ~ 95

Humid. Range (%RH)

15~98

Humid. Constancy (%RH)

±1.0 ±3.0 (No Load)

Temp. Accuracy (℃)

Constancy : ±0.1~±0.8, Homogeneity: ±0.5 ±2.0 ((No Load)

Test Space Dimension (mm)

660W×660D×1778H

890W×1068D×1905H

1220W×1524D×1905H

External Dimension (mm)

1560W×2000D×2750H

1790W×2400D×2850H

3950W×1980D×3000H

Cooling Methods

Air-Cooled/Water-Cooled

Power

AC380V±10%,50HZ,3/N/PE



Options

Standard Version

Necessary test tools

Independent power supply units for specimens

Independent sensors for specimen protection (NE60519-2.1993)

1 Entry port Φ100mm or RJ45 interface

1 Entry port Φ100mm



Nitrogen gas auxiliary device



Spare parts package



E-management and cyber-software







Industrial Robot Intelligent Temperature Humidity Chamber ISO14001 0

Features

Triad control system: AGV robot, center control unit and automatic testing chamber

Automatic door and automatic charge for specimens

Automatic transmission design for feeding specimens

Optional manual, semi-automatic and automatic operation models

Up to 20℃ min temperature change rate for homogeneous temperature linear changing

Dry air blowing system prevent specimen's surfaces from dewing in rapid temperature change

Fashionable desig of modular construction

7" colour touch screen display and 32 bit control system; interfce Ethernet/USB

4 Load power outlets for specimens with programmable control for protection

Design with independent sensors to prevent specimens from damages caused by dewing, overheat, breezeless and smog



Industrial Robot Intelligent Temperature Humidity Chamber ISO14001 1





Operation System Display

Industrial Robot Intelligent Temperature Humidity Chamber ISO14001 2

Application

  1. pharmaceuticals

  2. vehicle electronics

  3. cosmetics

  4. textiles

  5. auto parts

  6. packaging materials

  7. building materials

  8. electricityand the electrical products etc;



Industrial Robot Intelligent Temperature Humidity Chamber ISO14001 3

Why choose us?



1. We promised our customers that the testing equipments which were produced by Douwin are superior on quality. We provide products and service for numerous world-renowned enterprises,and get their high praise.



2. We always do our best to satisfy our customers by providing 24 hours online consultation service,and also we have a professional team who can provide the professsional program and technical support for our customers.


3. Before shipment, our quality inspection department will check the equipment to ensure that everything is okay with the goods. Moreover, we use the safe wooden packing to protect the goods from outside damage.



4. EXW or CIF are available,we have established long-term and stable cooperation with international logistics providers which can provide stable logistics services. Besides,customers can also specify logistics providers according to own choice.
